Jeep Wrangler: EXTERIOR LIGHTS / Automatic Headlights — If Equipped, Lights-On Reminder
Automatic Headlights
This system automatically turns the headlights
on or off according to ambient light levels. To
turn the system on, rotate the headlight switch
clockwise to the last detent for automatic
headlight operation. When the system is on, the
headlight time delay feature is also on. This
means the headlights will stay on for up to
90 seconds after you place the ignition into
the OFF position. To turn the automatic
system off, move the headlight switch out of the
AUTO position.
NOTE:
The engine must be running before the headlights
will come on in the automatic mode.
Lights-On Reminder
If the headlights, parking lights, or cargo lights
are left on after the ignition is placed in the OFF
position, a chime will sound when the driver’s
door is opened.
Automatic High Beam Headlamp Control
The Automatic High Beam Headlamp Control
system provides increased forward lighting at
night by automatically controlling the high
beams through the use of a camera mounted
on the vehicle’s header...
To activate the Front Fog Lights, turn on the
parking lights or low beam headlights and push
the fog light switch. Pushing the fog light switch
a second time will turn the front fog lights off...
Other information:
The engine block heater warms the engine, and
permits quicker starts in cold weather. Connect
the cord to a standard 110-115 Volt AC
electrical outlet with a grounded, three-wire
extension cord.
Diesel Engine Block Heater Cord Location
The engine block heater cord is found under the
hood bundled up next to the Power Distribution
Center (PDC)...
Place the gear selector in PARK, then push
and release the ENGINE START/STOP button.
The ignition will return to the OFF mode.
If the gear selector is not in PARK (with
vehicle stopped) and the ENGINE START/
STOP button is pushed once, the
transmission will automatically select PARK
and the engine will turn off while the ignition
will remain in the ACC mode (NOT the OFF
mode)...
